【Java小项目】--- 飞机大战(源码+注释)
前言：
“前些天发现了一个巨牛的人工智能学习网站，通俗易懂，风趣幽默
经过小新缜密的思考与亲身体验，忍不住分享一下给大家。有人工智能兴趣的朋友们，推荐大家一起学习 🎉点击直接访问🎉
里面有丰富的人工智能学习资料，真正做到从入门到入土，还不快来一起学习🎏🎏🎏
个人名片：
🐼作者简介：一名大一在校生
🐻❄️个人主页：小新爱学习.
🐼个人WeChat：hmmwx53
🕊️系列专栏：零基础学java ----- 重识c语言
🐓每日一句：青山一片云雾心安即归处。
文章目录
- 构思
- 主类(ShootGame)
- 英雄机(Hero)
- 飞行物(FlyingObject)
- 子弹(Bullet)
- 奖励蜜蜂(Bee)类
- 敌飞机类(AirPlane)
- 奖励接口
- 计分接口
- 源码图片获取，微信私
构思
首先，要把整体的游戏框架和内容构思出来(根据预先构思游戏里存在的组件内容和游戏功能抽象出指定类)。以我的小游戏为例：
-
1.主界面框架类：
显示开始界面 -
2.弹出界面类：
JDialog 窗体的功能是从一个窗体中弹出另一个窗体，就像是在使用 IE 浏览器时弹出的确定对话框，JDialog 窗体与 JFrame 窗体形式基本相同，设置窗体的特性时调用的方法名称都基本相同，如设置窗体大小、窗体关闭状态等 -
3.游戏面板类：GamePanel (extends JPanel)
真正显示飞机大战动态游戏画面，并且还添加了按钮JButton用于控制游戏开始暂停。 -
4.玩家飞机类：Hero
移动玩家飞机、画玩家飞机等其他与玩家飞机相关的方法 -
5.敌机类：AirPlane
移动敌机、画敌机 -
6.子弹类
移动子弹、绘制子弹 -
7碰撞类：Collision
检测各种碰撞情况 -
8.主类：Main
开启程序
主类(ShootGame)
package cn.tede.shoot;import javax.imageio.ImageIO;
import javax.swing.*;
import java.awt.*;
import java.awt.event.MouseAdapter;
import java.awt.event.MouseEvent;
import java.awt.image.BufferedImage;
import java.io.IOException;
import java.util.Arrays;
import java.util.Random;
import java.util.TimerTask;//import static java.util.concurrent.locks.StampedLock.STATE;public class ShootGame extends JPanel {public static final int WIDTH =400;public static final int HEIGHT =654;private int state;public static final int START = 0;public static final int RUNNING = 1;public static final int PAUSE = 2;public static final int GAME_OVER =4;public static BufferedImage background;public static BufferedImage start;public static BufferedImage airplane;public static BufferedImage bee;public static BufferedImage bullet;public static BufferedImage hero0;public static BufferedImage hero1;public static BufferedImage pause;public static BufferedImage gameover;private FlyingObject[] flyings = {}; //敌机数组private Bullet [] bullets = {}; //子弹数组private Hero hero = new Hero();//英雄鸡private Timer timer;//定时器private int intervel = 1000/100; //时间间隔，十毫秒private int score = 0;//得分
// public ShootGame(){
flyings = new FlyingObject[2];
flyings[0] = new AirPlane();
flyings[1] = new Bee();
bullets = new Bullet[1];
bullets[0] = new Bullet(180,300);
// }static{//静态代码块try {background= ImageIO.read(ShootGame.class.getResource("background.png"));start= ImageIO.read(ShootGame.class.getResource("start.png"));airplane = ImageIO.read(ShootGame.class.getResource("airplane.png"));bee = ImageIO.read(ShootGame.class.getResource("bee.png"));bullet = ImageIO.read(ShootGame.class.getResource("bullet.png"));//bullet = ImageIO.read(ShootGame.class.getResource("B1.png"));//hero0= ImageIO.read(ShootGame.class.getResource("C.png"));hero0= ImageIO.read(ShootGame.class.getResource("hero0.png"));hero1 = ImageIO.read(ShootGame.class.getResource("hero1.png"));pause= ImageIO.read(ShootGame.class.getResource("pause.png"));gameover = ImageIO.read(ShootGame.class.getResource("gameover.png"));} catch (IOException e) {e.printStackTrace();}}@Overridepublic void paint(Graphics g) {g.drawImage(background,0,0,null);//画背景图片paintHero(g);paintBullets(g);paintFlyingObject(g);paintScore(g);//画分数// paintPause(g);paintState(g);}/*** 画游戏状态**/public void paintState(Graphics g){switch(state){case START:g.drawImage(start,0,0,null);break;case PAUSE:g.drawImage(pause, 0, 0, null);break;case GAME_OVER:g.drawImage(gameover, 0, 0, null);break;}}/*** 画分数* @param g*/public void paintScore(Graphics g){Font font = new Font(Font.SANS_SERIF, Font.BOLD,4);g.setColor(new Color(0xffff0));//设置字体g.drawString("SCORE"+score,10,25);g.drawString("LIFE"+hero.getLife(),10,45);}//画英雄鸡public void paintHero(Graphics g){g.drawImage(hero.getImage(),hero.getX(),hero.getY(),null);}//画子弹public void paintBullets(Graphics g){for(int i = 0;i < bullets.length; i++){Bullet b = bullets[i];g.drawImage(b.getImage(),b.getX(),b.getY(),null);}}//画飞行物public void paintFlyingObject(Graphics g){for(int i = 0; i< flyings.length;i++){FlyingObject f = flyings[i];g.drawImage(f.getImage(),f.getX(),f.getY(),null);}}
// //画暂停
// public void paintPause(Graphics g){
// g.drawImage(pause,0,0,null);
// }//随机生成飞行物public static FlyingObject nextOne(){//返回 飞行物对象Random random = new Random();int type = random.nextInt(20);//生成随机数0-19if(type == 0){return new Bee();}else{return new AirPlane();}}int flyEnterIndex = 0;//飞行物入场public void enterAction () {flyEnterIndex++;if (flyEnterIndex % 40 == 0) {//每调用40次该方法FlyingObject obj = nextOne();//随机生成一个飞行物flyings = Arrays.copyOf(flyings, flyings.length + 1);//扩容flyings[flyings.length - 1] = obj;//放在最后一位}}/*实现飞行物移动*/public void stepAction() {for (int i = 0; i < flyings.length; i++){FlyingObject f = flyings[i];f.step();}for(int i = 0;i<bullets.length;i++){/*** 子弹走**/Bullet b = bullets[i];b.step();
// bullets[i].step();}hero.step();}int shootIndex = 0;//射击public void shootAction() {//调用30次该方法发射一次子弹，//英雄级打出子弹//扩容//追加数组shootIndex++;if (shootIndex % 30 == 0) {//每调用30次该方法Bullet [] bs = hero.shoot();//英雄鸡打出子弹bullets = Arrays.copyOf(bullets, bullets.length + bs.length);//扩容System.arraycopy(bs,0,bullets,bullets.length - bs.length,bs.length);}}public void bangAction() {for (int i = 0; i< bullets.length; i++){Bullet b = bullets[i];bang(b);}}private void bang(Bullet bullet) {int index = -1;for (int i = 0; i <flyings.length;i++){FlyingObject obj = flyings[i];if(obj.shootBy(bullet)){index = i;break;}}if(index != -1) {//击中FlyingObject one = flyings[index];//记录被击中的飞行物FlyingObject temp = flyings[index];//被击中的飞行物与最后一个飞行物交换flyings[index] = flyings[flyings.length - 1];flyings[flyings.length - 1] = temp;//删除最后一个飞行物(被击中的飞行物)flyings = Arrays.copyOf(flyings, flyings.length - 1);//检测one的类型，若果是敌人就加分if (one instanceof Enemy) {Enemy e = (Enemy) one;score += e.getScore();}if (one instanceof Award) {Award a = (Award) one;int type = a.getType();switch (type) {case Award.DOUBLE_FIRE:hero.addDoubleFire();break;case Award.LIFE:hero.addLife();break;}}}//如果one的类型就奖励，则设置奖励}/*** 删除越界的飞行物和子弹，小蜜蜂，飞机*/public void outOfBoundsAction() {int index = 0;FlyingObject[] flyingLives = new FlyingObject[flyings.length];//没有碰撞的飞行物for (int i = 0; i < flyings.length; i++) {FlyingObject f = flyings[i];if (!f.outOfBounds()) {flyingLives[index++] = f;//没有越界的存储到或者的数组}}flyings = Arrays.copyOf(flyingLives, index);//没有越界的都留着index = 0;Bullet[] bulletLives = new Bullet[bullets.length];//存储没有发生碰撞的子弹for (int i = 0; i < bullets.length; i++) {Bullet b = bullets[i];if (!b.outOfBounds()) {//如果没有越界bulletLives[index++] = b;}}bullets = Arrays.copyOf(bulletLives,index);}/*** 检测游戏是否结束*/public boolean isGameOver() {for (int i = 0; i < flyings.length; i++) {//遍历所有飞行物int index = -1;//没有发生碰撞FlyingObject obj = flyings[i];if(hero.hit(obj)){//检查英雄鸡与飞行物是否碰撞hero.subtractLife();//减命hero.setDoubleFire(0);//双倍火力清零index = i;//将碰撞飞行物的下标给到index}if(index!=-1){FlyingObject t = flyings[index];flyings[index] = flyings[flyings.length - 1];flyings[flyings.length - 1] = t;//发生碰撞的元素和最后一个元素交换flyings = Arrays.copyOf(flyings,flyings.length-1);}}return hero.getLife() <= 0;}/*** 检查游戏是否结束*/public void checkGameOverAction() {if(isGameOver()){//如果已经结束state = GAME_OVER;//改变状态为结束}}public void action(){//鼠标监听事件MouseAdapter i = new MouseAdapter(){public void mouseMoved(MouseEvent e) {//鼠标移动if(state == RUNNING) {int x = e.getX();int y = e.getY();hero.moveTo(x, y);}}public void mouseEntered(MouseEvent e){//鼠标进入if(state == PAUSE){state = RUNNING;}}@Overridepublic void mouseExited(MouseEvent e) {//鼠标退出if(state!=GAME_OVER&&state!=START){state = PAUSE;//游戏装态不是GAMEOVER ，鼠标离开窗口 ，设置暂停}}@Overridepublic void mouseClicked(MouseEvent mouseEvent) {//鼠标点击事件switch(state){case START:state = RUNNING;break;case GAME_OVER://当状态是结束的时候，点击鼠标，会重新初始化各个对象，状态变为开始flyings = new FlyingObject[0];bullets = new Bullet[0];hero = new Hero();score = 0;state = START;}}};this.addMouseListener(i);//处理鼠标点击事件this.addMouseMotionListener(i);//处理鼠标滑动操作//启动执行代码java.util.Timer timer = new java.util.Timer();timer.schedule(new TimerTask() {public void run() {if(state == RUNNING){enterAction();//飞行物入场stepAction();//飞行物走一步shootAction();bangAction();isGameOver();checkGameOverAction();//检查游戏结束outOfBoundsAction();}repaint();//重绘，调用paint方法}}, intervel ,intervel);//10毫秒以后，每隔10毫秒执行一次}public static void main(String[] args){JFrame frame = new JFrame("飞机大战");//画框ShootGame game = new ShootGame();frame.add(game);frame.setSize(WIDTH, HEIGHT);//窗口的大小frame.setAlwaysOnTop(true);//窗口在最上边frame.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);//点x关闭frame.setLocationRelativeTo(null);//设置窗体的初始记录frame.setVisible(true);//尽快调用paint方法game.action();}
}英雄机(Hero)
package cn.tede.shoot;import java.awt.image.BufferedImage;//英雄鸡
public class Hero extends FlyingObject {BufferedImage[] images = {};int index = 0;private int doubleFire;//双倍火力的子弹数量private int life;//命的数量public Hero() {life = 3;doubleFire = 0;this.image = ShootGame.hero0;images = new BufferedImage[]{ShootGame.hero0, ShootGame.hero1};width = image.getWidth();height = image.getHeight();x = 150;y = 400;}@Overridepublic void step() {if (images.length > 0) {image = images[index++ / 10%images.length];}}@Overridepublic boolean outOfBounds() {return false;}@Override//重写public boolean hitColumn() {return false;}//发射子弹public Bullet[] shoot() {int xStep = width / 4;int yStep = 20;if (doubleFire > 0) {//双倍火力Bullet[] bullets = new Bullet[5];//2bullets[0] = new Bullet(x + xStep, y - yStep);bullets[1] = new Bullet(x + 3 * xStep, y - yStep);bullets[2] = new Bullet(x + 2 * xStep, y - yStep);bullets[3] = new Bullet(x + 0 * xStep, y - yStep);bullets[4] = new Bullet(x + 4 * xStep, y - yStep);doubleFire -= 2;return bullets;} else {Bullet[] bullets = new Bullet[1];bullets[0] = new Bullet(x + 2 * xStep, y - yStep);return bullets;}}/**** @param x:鼠标x坐标位置* @param y;鼠标y坐标位置*/public void moveTo(int x, int y) {this.x = x- width/2;//hero.x+width/2;this.y = y - height/2;}public void addDoubleFire(){doubleFire += 40;}public void addLife(){life++;}//获取英雄鸡命数public int getLife(){return life;}// public boolean outOfBounds(){
// return false;
// }//减命public void subtractLife(){life--;}//重新设计双倍火力值public void setDoubleFire(int doubleFire){this.doubleFire = doubleFire;}//碰撞的算法public boolean hit(FlyingObject other){int x1 = other.x - this.width/2 ;int x2 = other.x + this.width/2 + this.width;int y1 = other.y - this.height/2 ;int y2 = other.y + other.height + other.height/2;return this.x + this.width/2>x1&&this.x+this.width/2<x2&&this.y+this.height/2>y1&&this.y+this.height/2<y2;}
}
飞行物(FlyingObject)
package cn.tede.shoot;
//父类
import java.awt.image.BufferedImage;public abstract class FlyingObject {protected int x;//x坐标protected int y;//y坐标protected int width;//宽protected int height;//高protected BufferedImage image;//图片public int getX() {return x;}public void setX(int x) {this.x = x;}public int getY() {return y;}public void setY(int y) {this.y = y;}public int getWidth() {return width;}public void setWidth(int width) {this.width = width;}public int getHeight() {return height;}public void setHeight(int height) {this.height = height;}public BufferedImage getImage() {return image;}public void setImage(BufferedImage image) {this.image = image;}public abstract void step();public boolean shootBy(Bullet bullet){int x= bullet.x;int y = bullet.y;return this.x<x&&x<this.x+width&&this.y<y && y<this.y+height;}/*** 检查是否出界* @return*/public abstract boolean outOfBounds();///*** 检测是否碰墙*/public abstract boolean hitColumn();
}子弹(Bullet)
package cn.tede.shoot;/*** 子弹*/
public class Bullet extends FlyingObject{private int speed = 3;//移动速度public Bullet(int x,int y){this.x = x;this.y = y;this.image = ShootGame.bullet;}@Overridepublic void step() {y -= speed;}@Overridepublic boolean outOfBounds() {return y<-height;}@Overridepublic boolean hitColumn() {return y<-height;}
}奖励蜜蜂(Bee)类
package cn.tede.shoot;import java.util.Random;//蜜蜂
public class Bee extends FlyingObject implements Award{private int xSpeed = 1;//x坐标的移动速度private int ySpeed = 2;//y坐标的移动速度private int awardType;//奖励类型public Bee(){this.image = ShootGame.bee;width = image.getWidth();height = image.getHeight();y = - height;//y = 200;x= (int)Math.random()*(ShootGame.WIDTH - width);Random r =new Random();//int x = r.nextInt(ShootGame.WIDTH - width);//x = 100;awardType = r.nextInt(2);}@Overridepublic int getType() {//奖励类型return awardType;}@Overridepublic void step() {x+= xSpeed;y+= ySpeed;if(x>ShootGame.WIDTH - width){xSpeed = -1;}if(x<0){xSpeed = 1;}}@Overridepublic boolean outOfBounds() {return y>ShootGame.HEIGHT;}@Overridepublic boolean hitColumn() {return false;}
}敌飞机类(AirPlane)
package cn.tede.shoot;public class AirPlane extends FlyingObject implements Enemy{private int speed = 2;//敌人飞机移动速度2public AirPlane(){this.image = ShootGame.airplane;width = image.getWidth();height = image.getHeight();y= -height;x = (int)(Math.random()*(ShootGame.WIDTH - width));
// x = 300;
// y = 190;}@Overridepublic int getScore() {return 5;}@Overridepublic void step() {y+=speed;}@Overridepublic boolean outOfBounds() {return y>ShootGame.HEIGHT;}@Overridepublic boolean hitColumn() {return y>ShootGame.HEIGHT;}
}奖励接口
package cn.tede.shoot;/*** 奖励*/
public interface Award {int DOUBLE_FIRE = 0;//双倍火力int LIFE = 1;//一条命/*** 获得奖励的类型为上面的0或者1* @return*/int getType();
}计分接口
ackage cn.tede.shoot;/*** 敌人*/
public interface Enemy {int getScore();
}
–
源码图片获取，微信私
