mapboxGL卷帘实现
概述
卷帘对比是webgis中常见的一种对比方式，本文讲述一下如何在mapboxGL中实现卷帘对比。
效果
实现思路
- 通过
input[range]实现卷帘的操作； - 通过地图的事件实现两个地图的联动操作。
实现代码
head><body><div class="swipe"><input type="range" id="swipe"/><div class="swipe-bar" id="swipeBar">div>div><div class="map" id="map1">map1div><div class="map" id="map2">map2div><script src='https://api.mapbox.com/mapbox-gl-js/v1.12.0/mapbox-gl.js'>script><script>const style1 = {"version": 8,"name": "lzugis","sources": {"nav": {"type": "raster","tiles": ['https://webst01.is.autonavi.com/appmaptile?style=6&x={x}&y={y}&z={z}'],"tileSize": 256}},"layers": [{"id": "nav","type": "raster","source": "nav","minzoom": 0,"maxzoom": 17}]}const style2 = {"version": 8,"name": "lzugis","sources": {"nav": {"type": "raster","tiles": ['http://webrd01.is.autonavi.com/appmaptile?x={x}&y={y}&z={z}&lang=zh_cn&size=1&scale=1&style=8'],"tileSize": 256}},"layers": [{"id": "nav","type": "raster","source": "nav","minzoom": 0,"maxzoom": 17}]}const doms = document.getElementsByClassName('map')const maps = []const styles = [style1, style2]for (let i = 0; i < doms.length; i++) {const dom = doms[i];maps.push(new mapboxgl.Map({container: dom,style: styles[i],center: [103.081163, 37.1612],zoom: 3.5,minZoom: 2,maxZoom: 18}))}maps.forEach(map => {const mapDom = map.getContainer().getAttribute('id')// 鼠标进入的时候注册事件map.on('mouseover', e => {const mouseDom = e.target.getContainer().getAttribute('id')if(mouseDom === mapDom) {map.on('move', moveEvent)} else {map.off('move', moveEvent)}})// 鼠标移除的时候关闭事件map.on('mouseout', e => {maps.forEach(map => {map.off('move', moveEvent)})})})function moveEvent(e) {const c = e.target.getCenter()const d = e.target.getContainer().getAttribute('id')const z = e.target.getZoom()maps.forEach(map => {if(d !== map.getContainer().getAttribute('id')) {map.setCenter(c)map.setZoom(z)}})}const map1 = document.getElementById('map1')const map2 = document.getElementById('map2')const WIDTH = map1.clientWidthconst HEIGHT = map1.clientHeightconst swipe = document.getElementById('swipe')const MAX = 1000swipe.setAttribute('min', 0)swipe.setAttribute('max', MAX)swipe.setAttribute('value', MAX / 2)swipe.oninput = function(e) {setStyle()}setStyle()function setStyle() {const v = swipe.valueconst left = Math.ceil((v / MAX) * WIDTH)map1.style.clip = `rect(0, ${left}px, ${HEIGHT}px, 0)`map2.style.clip = `rect(0, ${WIDTH}px, ${HEIGHT}px, ${left}px)`// 设置bar样式const swipeBar = document.getElementById('swipeBar')swipeBar.style.left = `${left - 2}px`// 设置swipe样式const hWIDTH = MAX / 2const isLeft = v < hWIDTHconst offsetL = Math.abs(((hWIDTH - v) / hWIDTH) * 18)swipe.style.left = isLeft ? `-${offsetL}px` : `${offsetL}px`}script>
body>
html>
