Hook启动插件中四大组件

在上一节，我们主要介绍了如果通过反射来加载插件中的类，调用类中的方法；既然插件是一个apk，其实最重要的是启动插件中的Activity、Service等组件，因为像Activity这些组件，需要在清单文件中注册，否则启动的时候会报下面的错误

android.content.ActivityNotFoundException:
Unable to find explicit activity class {com.lay.image_process/com.lay.image_process.MainActivity2};
have you declared this activity in your AndroidManifest.xml?

那么如果要启动插件中的Activity，就需要将其注册到宿主app的清单文件中

1 Activity的启动流程

其实想要启动插件中的四大组件，例如Activity，就需要熟悉Activity的启动流程，为什么在没有注册的情况下，不能启动

1.1 启动插件Activity思路梳理

开头我们提到，为什么没有注册过的Activity不能启动？是因为当系统启动一个Activity的时候，需要通过AMS检测，当前被启动的Activity是否被注册，如果没有注册，那么就会报错，所以我们需要采用Hook的方式来欺骗系统已达到我们的目的。

在应用层，我们能看到的就是，宿主app启动了插件中的Activity，其实在内部做了很多处理：\

（1）首先将插件中的Activity替换成宿主中已经注册过的ProxyActivity，在启动的时候，通过AMS检测发现当前启动的Activity已经被注册过了，那么就会继续往下执行；
（2）当AMS检测完成之后，再将宿主中的ProxyActivity替换成插件中的Activity，最终启动的就是插件中的Activity。

//实际启动代码

val intent = Intent()
intent.component = ComponentName("com.lay.plugin","com.lay.plugin.MainActivity")
startActivity(intent)

我们看到启动方式很简单，但是内部其实做了很多的Hook处理，如果想知道怎么用，那么就跟着这个思路一起走下去。

1.2 从源码理解Activity启动流程

对于Activity的启动流程，我想大家都非常了解了，记住关键的几个类Instrument、ActivityManagerService、ApplicationThread......，下面简单介绍下流程。

当调用Instrument的execStartActivity方法时，通过ActivityTaskManager.getService()获取AMS服务，调用AMS的startActivity方法，并返回检测的结果。

public ActivityResult execStartActivity(Context who, IBinder contextThread, IBinder token, Activity target,Intent intent, int requestCode, Bundle options) {IApplicationThread whoThread = (IApplicationThread) contextThread;Uri referrer = target != null ? target.onProvideReferrer() : null;if (referrer != null) {intent.putExtra(Intent.EXTRA_REFERRER, referrer);}// ......try {intent.migrateExtraStreamToClipData(who);intent.prepareToLeaveProcess(who);//这里就是通过ActivityTaskManager获取AMS服务，调用AMS的startActivity方法，并返回结果int result = ActivityTaskManager.getService().startActivity(whoThread,who.getOpPackageName(), who.getAttributionTag(), intent,intent.resolveTypeIfNeeded(who.getContentResolver()), token,target != null ? target.mEmbeddedID : null, requestCode, 0, null, options);  checkStartActivityResult(result, intent);} catch (RemoteException e) {throw new RuntimeException("Failure from system", e);}return null;
}

我们看一下checkStartActivityResult方法究竟做了什么？我们看一下START_CLASS_NOT_FOUND这个结果，最终抛出的错误是不是就是文章开头的错误

public static void checkStartActivityResult(int res, Object intent) {if (!ActivityManager.isStartResultFatalError(res)) {return;}switch (res) {case ActivityManager.START_INTENT_NOT_RESOLVED:case ActivityManager.START_CLASS_NOT_FOUND:if (intent instanceof Intent && ((Intent)intent).getComponent() != null)throw new ActivityNotFoundException("Unable to find explicit activity class "+ ((Intent)intent).getComponent().toShortString()+ "; have you declared this activity in your AndroidManifest.xml?");throw new ActivityNotFoundException("No Activity found to handle " + intent);case ActivityManager.START_PERMISSION_DENIED:throw new SecurityException("Not allowed to start activity "+ intent);case ActivityManager.START_FORWARD_AND_REQUEST_CONFLICT:throw new AndroidRuntimeException("FORWARD_RESULT_FLAG used while also requesting a result");case ActivityManager.START_NOT_ACTIVITY:throw new IllegalArgumentException("PendingIntent is not an activity");case ActivityManager.START_NOT_VOICE_COMPATIBLE:throw new SecurityException("Starting under voice control not allowed for: " + intent);case ActivityManager.START_VOICE_NOT_ACTIVE_SESSION:throw new IllegalStateException("Session calling startVoiceActivity does not match active session");case ActivityManager.START_VOICE_HIDDEN_SESSION:throw new IllegalStateException("Cannot start voice activity on a hidden session");case ActivityManager.START_ASSISTANT_NOT_ACTIVE_SESSION:throw new IllegalStateException("Session calling startAssistantActivity does not match active session");case ActivityManager.START_ASSISTANT_HIDDEN_SESSION:throw new IllegalStateException("Cannot start assistant activity on a hidden session");case ActivityManager.START_CANCELED:throw new AndroidRuntimeException("Activity could not be started for "+ intent);default:throw new AndroidRuntimeException("Unknown error code "+ res + " when starting " + intent);}
}

也就是说在这个位置就已经检测完成，当前启动的Activity是否在清单文件中注册，也就是说，Hook点要在这个检测方法之前，完成对插件Activity的替换，这是Hook点1.

我们接着往下看AMS里主要做了啥

public class ActivityTaskManagerService extends IActivityTaskManager.Stub

ActivityTaskManagerService继承自IActivityTaskManager.Stub接口，作为一个服务端的角色，接受客户端的请求，例如启动Activity，AMS除了做Intent启动的Activity检测之外，还做了什么事呢？

在ATMS中调用startActivity方法，最终是调用了startActivityAsUser方法，这个方法中，首先检查了调用者的权限，然后调用了ActivityStartController一系列方法，用于启动前的任务栈处理

private int startActivityAsUser(IApplicationThread caller, String callingPackage,@Nullable String callingFeatureId, Intent intent, String resolvedType,IBinder resultTo, String resultWho, int requestCode, int startFlags,ProfilerInfo profilerInfo, Bundle bOptions, int userId, boolean validateIncomingUser) {assertPackageMatchesCallingUid(callingPackage);enforceNotIsolatedCaller("startActivityAsUser");//检查调用者的权限userId = getActivityStartController().checkTargetUser(userId, validateIncomingUser,Binder.getCallingPid(), Binder.getCallingUid(), "startActivityAsUser");// TODO: Switch to user app stacks here.return getActivityStartController().obtainStarter(intent, "startActivityAsUser").setCaller(caller).setCallingPackage(callingPackage).setCallingFeatureId(callingFeatureId).setResolvedType(resolvedType).setResultTo(resultTo).setResultWho(resultWho).setRequestCode(requestCode).setStartFlags(startFlags).setProfilerInfo(profilerInfo).setActivityOptions(bOptions).setUserId(userId).execute();}

再深入的源码，大家可以自己去查看，最终AMS会判断启动这个Activity的进程是否启动，没有启动的话就启动app进程，如果已经启动了会调用realStartActivityLocked方法

void startSpecificActivity(ActivityRecord r, boolean andResume, boolean checkConfig) {// Is this activity's application already running?final WindowProcessController wpc =mService.getProcessController(r.processName, r.info.applicationInfo.uid);boolean knownToBeDead = false;if (wpc != null && wpc.hasThread()) {try {realStartActivityLocked(r, wpc, andResume, checkConfig);return;} catch (RemoteException e) {Slog.w(TAG, "Exception when starting activity "+ r.intent.getComponent().flattenToShortString(), e);}// If a dead object exception was thrown -- fall through to// restart the application.knownToBeDead = true;}r.notifyUnknownVisibilityLaunchedForKeyguardTransition();final boolean isTop = andResume && r.isTopRunningActivity();mService.startProcessAsync(r, knownToBeDead, isTop, isTop ? "top-activity" : "activity");
}

在realStartActivityLocked方法中，首先会创建一个启动Activity的Transaction，会通过ApplicationThread回调给客户端启动Activity，在AMS和客户端通信时，有两个对象需要注意：ActivityThread和ApplicationThread，ApplicationThread其实是ActivityThead在AMS的代理对象，AMS通过调用ApplicationThread与ActivityThead建立通信

boolean realStartActivityLocked(ActivityRecord r, WindowProcessController proc,boolean andResume, boolean checkConfig) throws RemoteException {// The LaunchActivityItem also contains process configuration, so the configuration change// from WindowProcessController#setProcess can be deferred. The major reason is that if// the activity has FixedRotationAdjustments, it needs to be applied with configuration.// In general, this reduces a binder transaction if process configuration is changed.//......// Create activity launch transaction.final ClientTransaction clientTransaction = ClientTransaction.obtain(proc.getThread(), r.appToken);final boolean isTransitionForward = r.isTransitionForward();clientTransaction.addCallback(LaunchActivityItem.obtain(new Intent(r.intent),System.identityHashCode(r), r.info,// TODO: Have this take the merged configuration instead of separate global// and override configs.mergedConfiguration.getGlobalConfiguration(),mergedConfiguration.getOverrideConfiguration(), r.compat,r.getFilteredReferrer(r.launchedFromPackage), task.voiceInteractor,proc.getReportedProcState(), r.getSavedState(), r.getPersistentSavedState(),results, newIntents, r.takeOptions(), isTransitionForward,proc.createProfilerInfoIfNeeded(), r.assistToken, activityClientController,r.createFixedRotationAdjustmentsIfNeeded(), r.shareableActivityToken,r.getLaunchedFromBubble()));// Schedule transaction.mService.getLifecycleManager().scheduleTransaction(clientTransaction);
}

所以AMS这里的作用就是：检测Activity合法性、检测app进程是否启动、通过ApplicationThead与ActivityThead建立通信。

private class ApplicationThread extends IApplicationThread.Stub {@Overridepublic void scheduleTransaction(ClientTransaction transaction) throws RemoteException {ActivityThread.this.scheduleTransaction(transaction);}

我们看下服务端的代理对象ApplicationThread，主要是处理AMS端的请求，例如realStartActivityLocked方法中创建的启动Activity的ClientTransaction，接收到之后，交给了ActivityThread处理。

首先我们看下ActivityThread是什么，我们看到它是继承自ClientTransactionHandler，也就是说，在App进程内的处理，都是通过Handler来发送消息

public final class ActivityThread extends ClientTransactionHandler

public abstract class ClientTransactionHandler {// Schedule phase related logic and handlers./** Prepare and schedule transaction for execution. */void scheduleTransaction(ClientTransaction transaction) {transaction.preExecute(this);sendMessage(ActivityThread.H.EXECUTE_TRANSACTION, transaction);}
}

对于EXECUTE_TRANSACTION消息类型，就是用来处理AMS端发送来的消息

case EXECUTE_TRANSACTION:final ClientTransaction transaction = (ClientTransaction) msg.obj;mTransactionExecutor.execute(transaction);if (isSystem()) {// Client transactions inside system process are recycled on the client side// instead of ClientLifecycleManager to avoid being cleared before this// message is handled.transaction.recycle();}// TODO(lifecycler): Recycle locally scheduled transactions.break;

最终是调用了TransactionExecutor的execute方法，在execute方法中，调用executeCallbacks方法，我们可以在realStartActivityLocked方法中看到，在transaction添加了callback，所以这个方法就是执行这些callback

public void execute(ClientTransaction transaction) {if (DEBUG_RESOLVER) Slog.d(TAG, tId(transaction) + "Start resolving transaction");executeCallbacks(transaction);executeLifecycleState(transaction);mPendingActions.clear();if (DEBUG_RESOLVER) Slog.d(TAG, tId(transaction) + "End resolving transaction");
}

executeCallbacks方法比较简单，就是遍历获取所有的callback，然后调用callback的execute方法，也就是LaunchActivityItem的execute方法

public void executeCallbacks(ClientTransaction transaction) {final List callbacks = transaction.getCallbacks();if (callbacks == null || callbacks.isEmpty()) {// No callbacks to execute, return early.return;}final int size = callbacks.size();for (int i = 0; i < size; ++i) {final ClientTransactionItem item = callbacks.get(i);if (DEBUG_RESOLVER) Slog.d(TAG, tId(transaction) + "Resolving callback: " + item);final int postExecutionState = item.getPostExecutionState();final int closestPreExecutionState = mHelper.getClosestPreExecutionState(r,item.getPostExecutionState());if (closestPreExecutionState != UNDEFINED) {cycleToPath(r, closestPreExecutionState, transaction);}item.execute(mTransactionHandler, token, mPendingActions);item.postExecute(mTransactionHandler, token, mPendingActions);if (r == null) {// Launch activity request will create an activity record.r = mTransactionHandler.getActivityClient(token);}if (postExecutionState != UNDEFINED && r != null) {// Skip the very last transition and perform it by explicit state request instead.final boolean shouldExcludeLastTransition =i == lastCallbackRequestingState && finalState == postExecutionState;cycleToPath(r, postExecutionState, shouldExcludeLastTransition, transaction);}}
}

在LaunchActivityItem的execute方法中，执行了ClientTransactionHandler的handleLaunchActivity方法，也就是ActivityThread的handleLaunchActivity方法，这里才是真正要启动这个Activity。

@Override
public void execute(ClientTransactionHandler client, IBinder token,PendingTransactionActions pendingActions) {Trace.traceBegin(TRACE_TAG_ACTIVITY_MANAGER, "activityStart");ActivityClientRecord r = client.getLaunchingActivity(token);client.handleLaunchActivity(r, pendingActions, null /* customIntent */);Trace.traceEnd(TRACE_TAG_ACTIVITY_MANAGER);
}

在performLaunchActivity方法中，通过Instrument类来创建新的Activity，并执行Activity的onCreate、onStart、onResume方法等，Activity就算是正式启动，所以第二个Hook点，我们知道了吗？

因为在performLaunchActivity方法调用之前，Activity都不算是真正地启动，也就是说，将宿主中的ProxyActivity替换成插件的Activity就需要在performLaunchActivity方法之前

2 Hook方式实现插件四大组件启动

通过上面的源码，我们知道了AMS在什么时机去检测Activity合法性，以及Activity什么时候真正地启动，所以我们分步骤，先处理AMS合法性校验问题。

2.1 Hook AMS

首先我们先看一下，如何通过Hook的方式，欺骗AMS过Activity合法性检测这一关，因为从前面的源码我们知道，调用startActivity最终会在Instrument的execStartActivity方法中检测，就是下面这两行代码

//  位置①
int result = ActivityTaskManager.getService().startActivity(whoThread,who.getOpPackageName(), who.getAttributionTag(), intent,intent.resolveTypeIfNeeded(who.getContentResolver()), token,target != null ? target.mEmbeddedID : null, requestCode, 0, null, options);
checkStartActivityResult(result, intent);

首先我们先看一下ActivityTaskManager.getService()最终返回的是一个IActivityTaskManager代理对象，是从IActivityTaskManagerSingleton中取出来的；

public static IActivityTaskManager getService() {return IActivityTaskManagerSingleton.get();
}@UnsupportedAppUsage(trackingBug = 129726065)
private static final Singleton IActivityTaskManagerSingleton =new Singleton() {@Overrideprotected IActivityTaskManager create() {final IBinder b = ServiceManager.getService(Context.ACTIVITY_TASK_SERVICE);return IActivityTaskManager.Stub.asInterface(b);}};

所以想要代替系ActivityTaskManager.getService()的返回值，首先反射获取IActivityTaskManagerSingleton这个属性

val clazz4ATM = Class.forName("android.app.ActivityTaskManager")
val filed = clazz4ATM.getDeclaredField("IActivityTaskManagerSingleton")
filed.isAccessible = true
//获取ActivityTaskManager中IActivityTaskManagerSingleton属性的值
val IActivityTaskManagerSingletonField = filed.get(null)

我们看到，IActivityTaskManagerSingleton其实是一个单例，需要通过get方法才能获取真正的实例，那么我们先看下Singleton是啥

public abstract class Singleton {@UnsupportedAppUsagepublic Singleton() {}@UnsupportedAppUsageprivate T mInstance;protected abstract T create();@UnsupportedAppUsagepublic final T get() {synchronized (this) {if (mInstance == null) {mInstance = create();}return mInstance;}}
}

其实还是比较简单的一个单例类，通过get方法拿到的其实就是mInstance，也就是说getService()拿到的就是这个mInstance，只不过是对IActivityTaskManager做了一层封装。

//从Singleton中获取对象
val singletonClazz = Class.forName("android.util.Singleton")
val mInstance = singletonClazz.getDeclaredField("mInstance")
mInstance.isAccessible = true
val taskManagerInstance = mInstance.get(IActivityTaskManagerSingletonField)

那么之前通过反射，拿到了Singleton对象，那么现在通过反射获取mInstance属性就拿到了getService()的返回值。

既然我们要hook系统的执行方式，当我们调用startActivity的时候，系统流程一步一步执行到位置①，这个时候，我们把getService()的返回值替换，换成我们自己处理过的IActivityTaskManager，从而

2.1.1 动态代理在Hook中的使用

因为我们想要替换getService()的返回值，而且返回值是一个IActivityTaskManager接口对象，其实第一时间就会想到动态代理，那么动态代理是什么原理呢？

interface proxyInterface{fun execute()
}

例如有一个接口，如果我们想要执行execute方法，那么就需要实现一个具体类，然后调用execute方法，这样其实在程序运行之前，就已经知道执行者是谁了；而动态代理则是程序在运行时，动态生成一个对象，这个时候才能知道执行者是谁，例如：

val instance = Proxy.newProxyInstance(classLoader, arrayOf(proxyInterface::class.java),object : InvocationHandler{override fun invoke(proxy: Any?,method: java.lang.reflect.Method?,args: Array?): Any {//Log.e("TAG","执行execute方法之前")return method?.invoke(proxy,args)!!}})
(instance as proxyInterface).execute()

通过Proxy调用newProxyInstance方法，传入的参数为类加载器、接口的class对象，需要实现一个接口InvocationHandler，其中method为调用者调用的某个方法，这个方法调用之前，可以插入一些逻辑判断，更为灵活；

这样就意味着，我们可以创建一个IActivityTaskManager的动态代理对象，替换系统的getService()返回的IActivityTaskManager对象，那么在动态代理对象调用startActivity之前，可以对入参做处理。

val proxyClazz = Class.forName("android.app.IActivityTaskManager")
val newTaskManagerInstance = Proxy.newProxyInstance(Thread.currentThread().contextClassLoader, arrayOf(proxyClazz),object : InvocationHandler{override fun invoke(proxy: Any?, method: Method?, args: Array?): Any {//做相应参数的处理return method?.invoke(taskManagerInstance,args)!!}})
//替换
mInstance.set(singletonClazz,newTaskManagerInstance)

因为IActivityTaskManager中的方法非常多，因此需要根据方法名去过滤，只能对startActivity方法进行处理，当startActivity执行时，首先会将Intent类型参数取出来，把Intent替换成宿主中的ProxyActivity，但是真实的Intent不能丢掉，等合适的时间会重置回来，因此可以保存在代理的Intent中

method?.let {if (it.name == "startActivity") {//修改Intent的值args?.let { args ->var targetIndex = 0for (index in args.indices) {if (args[index] is Intent) {targetIndex = indexbreak}}val oldIntent = args[targetIndex] as Intentval intentProxy = Intent()intentProxy.component = ComponentName("com.lay.image_process","com.lay.image_process.ProxyActivity")intentProxy.putExtra("old_intent", oldIntent)args[targetIndex] = intentProxy}}
}

这个时候，当我们启动插件中的Activity时，启动的就是这个代理Activity；这里需要说明一点就是，因为源码是Java写的，所以我们在Hook时，尽量还是用跟源码一致的语言，否则可能会出现类型不匹配的问题，详细源码见附录1

2.2 Hook ActivityThread

通过前面的源码，我们知道在AMS的realStartActivityLocked方法中（辛苦伙伴们自己爬楼），是创建了一个ClientTransaction对象，然后在ClientTransaction对象中添加了callback，在启动Activity的时候，添加的callback对象为LaunchActivityItem，我们看下LaunchActivityItem源码

public class LaunchActivityItem extends ClientTransactionItem {@UnsupportedAppUsageprivate Intent mIntent;private int mIdent;@UnsupportedAppUsageprivate ActivityInfo mInfo;

其他的先不用看，第一个参数就是mIntent，这个mIntent其实就是在之前AMS中替换的Intent，现在的目标就是将其替换成插件中的Activity。

那么在哪拿到这个对象呢？我们继续爬楼，在之前提到ActivityThread其实是一个Handler，通过Message的tag来分别处理数据。

case EXECUTE_TRANSACTION:final ClientTransaction transaction = (ClientTransaction) msg.obj;mTransactionExecutor.execute(transaction);if (isSystem()) {// Client transactions inside system process are recycled on the client side// instead of ClientLifecycleManager to avoid being cleared before this// message is handled.transaction.recycle();}// TODO(lifecycler): Recycle locally scheduled transactions.break;

当启动Activity的时候，AMS通过ApplicationThread代理发送的消息类型为EXECUTE_TRANSACTION，也就是说，我们可以Hook系统的Handler，当接收到EXECUTE_TRANSACTION消息时，把Intent给替换掉。

在Activity中有一个Handler类H，这个类就负责接收Message然后处理

class H extends Handler{public static final int EXECUTE_TRANSACTION = 159;
}

我们可以看到，在ActivityThread中是直接new出来，我们知道，当调用Handler的send方法时，在底层是调用了dispatchMessage方法从消息池中取出数据分发

@UnsupportedAppUsage
final H mH = new H();

因为空参构造方法，mCallback是空的，所以会直接走handleMessage方法，所以我们如果想拿消息自己去处理，那么可以自己创建一个mCallback对象赋值给mH的callback，那么是不就能走我们自己的逻辑处理了呢

public void dispatchMessage(@NonNull Message msg) {if (msg.callback != null) {handleCallback(msg);} else {if (mCallback != null) {if (mCallback.handleMessage(msg)) {return;}}handleMessage(msg);}
}

首先我们先把前面梳理的思路通过反射梳理出来，有几个属性先强调一下，一个是sCurrentActivityThread，这个是ActivityThread类中的一个属性，就是当前对象，通过获取这个属性的值，来获取ActivityThread中的非静态属性值；还有一个就是Handler中的mCallback，因为系统Handler创建时没有设置callback，所以我们自己创建了一个callback，并给它赋值

public static void hookHandler() {try {Class activityThreadClazz = Class.forName("android.app.ActivityThread");//获取到ActivityThread对象Field sCurrentActivityThreadField = activityThreadClazz.getDeclaredField("sCurrentActivityThread");sCurrentActivityThreadField.setAccessible(true);Object sCurrentActivityThread = sCurrentActivityThreadField.get(null);//获取mH属性Field mHField = activityThreadClazz.getDeclaredField("mH");mHField.setAccessible(true);//获取mH Handler对象Object mH = mHField.get(sCurrentActivityThread);//反射HandlerClass handlerClazz = Class.forName("android.os.Handler");Field mCallbackField = handlerClazz.getDeclaredField("mCallback");mCallbackField.setAccessible(true);//创建callback对象Handler.Callback callback = new Handler.Callback() {@Overridepublic boolean handleMessage(@NonNull Message msg) {//处理Intent替换的逻辑doIntentReplace(msg)return false;}};//给系统Handler赋值mCallbackField.set(mH, callback);} catch (Exception exception) {}}

好了，那么下面的逻辑，主要就是给Intent替换。我们主要关心EXECUTE_TRANSACTION这个tag的处理。

public class ClientTransaction implements Parcelable, ObjectPoolItem {/** A list of individual callbacks to a client. */@UnsupportedAppUsageprivate List mActivityCallbacks;/*** Add a message to the end of the sequence of callbacks.* @param activityCallback A single message that can contain a lifecycle request/callback.*/public void addCallback(ClientTransactionItem activityCallback) {if (mActivityCallbacks == null) {mActivityCallbacks = new ArrayList<>();}mActivityCallbacks.add(activityCallback);}
}

当我们获取到Message携带的对象，其实就是ClientTransaction，我们看下源码，当调用addCallback的时候，就是将ClientTransactionItem放在了mActivityCallbacks中，所以拿到mActivityCallbacks就能拿到我们想要的LaunchActivityItem

private static void doIntentReplace(Message msg) {switch (msg.what) {case 159://获取Class transactionClazz = msg.obj.getClass();try {Field mActivityCallbacksField = transactionClazz.getDeclaredField("mActivityCallbacks");mActivityCallbacksField.setAccessible(true);List callbacks = (List) mActivityCallbacksField.get(msg.obj);for (int i = 0; i < callbacks.size(); i++) {Object transactionItem = callbacks.get(i);//判断是不是LaunchActivityItemif (transactionItem.getClass().getName().equals("android.app.servertransaction.LaunchActivityItem")) {//获取mIntent属性Field mIntentField = transactionItem.getClass().getDeclaredField("mIntent");mIntentField.setAccessible(true);Log.e("TAG", "intent " + mIntentField.get(transactionItem));Intent mIntent = (Intent) mIntentField.get(transactionItem);Intent oldIntent = mIntent.getParcelableExtra("old_intent");mIntentField.set(transactionItem, oldIntent);
//                            mIntent.setComponent(oldIntent.getComponent()); 这种方式同样有效}}} catch (Exception e) {e.printStackTrace();}break;}}

这样我们拿到了LaunchActivityItem中的mIntent之后，这个其实是代理的Intent，需要从中取出我们之前在HookAMS的时候保存的真正的Intent，并赋值，这个时候，Activity启动的时候启动的就是插件中的Activity。

其实，我们在学习插件化的时候，其实知识点还是很多的，像：Android类加载机制、Activity的启动流程、Hook原理等，并且能够深入源码，这一块其实是面试的重点和难点；这一节我们已经启动了插件中的Activity，其实像Service、BroadcastReceiver等组件，原理是一致，像Activity已经启动了，但是资源文件并没有被加载，所以下一节将着重介绍如何加载插件中的资源。

附录1 Hook AMS(Android Q版本)

public static void HookAMS() {try {Class atmClazz = Class.forName("android.app.ActivityTaskManager");Field iActivityTaskManagerSingletonField = atmClazz.getDeclaredField("IActivityTaskManagerSingleton");iActivityTaskManagerSingletonField.setAccessible(true);Object atmSingleton = iActivityTaskManagerSingletonField.get(null);Class singletonClazz = Class.forName("android.util.Singleton");Field mInstanceField = singletonClazz.getDeclaredField("mInstance");mInstanceField.setAccessible(true);final Object atmService = mInstanceField.get(atmSingleton);Class proxyClazz = Class.forName("android.app.IActivityTaskManager");Object newProxyInstance = Proxy.newProxyInstance(Thread.currentThread().getContextClassLoader(), new Class[]{proxyClazz}, new InvocationHandler() {@Overridepublic Object invoke(Object proxy, Method method, Object[] args) throws Throwable {if (method.getName().equals("startActivity")) {int targetIndex = 0;//修改Intent的值for (int i = 0; i < args.length; i++) {if (args[i] instanceof Intent) {targetIndex = i;break;}}Intent oldIntent = (Intent) args[targetIndex];Intent proxyIntent = new Intent();proxyIntent.setComponent(new ComponentName("com.lay.image_process", "com.lay.image_process.MainActivity2"));proxyIntent.putExtra("old_intent", oldIntent);args[targetIndex] = proxyIntent;}Log.e("TAG", "atmService=" + atmService + " method=" + method + ", args=" + args);return method.invoke(atmService, args);}});mInstanceField.set(atmSingleton, newProxyInstance);} catch (Exception e) {Log.e("TAG", "e--" + e.getMessage());e.printStackTrace();}
}

附录2 Hook Handler(Android Q版本)

public static void hookHandler() {try {Class activityThreadClazz = Class.forName("android.app.ActivityThread");//获取到ActivityThread对象Field sCurrentActivityThreadField = activityThreadClazz.getDeclaredField("sCurrentActivityThread");sCurrentActivityThreadField.setAccessible(true);Object sCurrentActivityThread = sCurrentActivityThreadField.get(null);//获取mH属性Field mHField = activityThreadClazz.getDeclaredField("mH");mHField.setAccessible(true);//获取mH Handler对象Object mH = mHField.get(sCurrentActivityThread);//反射HandlerClass handlerClazz = Class.forName("android.os.Handler");Field mCallbackField = handlerClazz.getDeclaredField("mCallback");mCallbackField.setAccessible(true);//创建callback对象Handler.Callback callback = new Handler.Callback() {@Overridepublic boolean handleMessage(@NonNull Message msg) {//处理Intent替换的逻辑doIntentReplace(msg);return false;}};//给系统Handler赋值mCallbackField.set(mH, callback);} catch (Exception exception) {}}private static void doIntentReplace(Message msg) {switch (msg.what) {case 159://获取Class transactionClazz = msg.obj.getClass();try {Field mActivityCallbacksField = transactionClazz.getDeclaredField("mActivityCallbacks");mActivityCallbacksField.setAccessible(true);List callbacks = (List) mActivityCallbacksField.get(msg.obj);for (int i = 0; i < callbacks.size(); i++) {Object transactionItem = callbacks.get(i);//判断是不是LaunchActivityItemif (transactionItem.getClass().getName().equals("android.app.servertransaction.LaunchActivityItem")) {//获取mIntent属性Field mIntentField = transactionItem.getClass().getDeclaredField("mIntent");mIntentField.setAccessible(true);Log.e("TAG", "intent " + mIntentField.get(transactionItem));Intent mIntent = (Intent) mIntentField.get(transactionItem);Intent oldIntent = mIntent.getParcelableExtra("old_intent");mIntentField.set(transactionItem, oldIntent);
//                            mIntent.setComponent(oldIntent.getComponent()); 这种方式同样有效}}} catch (Exception e) {e.printStackTrace();}break;}}

作者：Ghelper
链接：https://juejin.cn/post/7144243095989649415
